ZWIN-YC08 DUST MONITOR

2023/08/17 poeira voadora produtos 396 0

ZWIN-YC08 Dust Online Monitor is designed to online real-time monitoring of multi environmental factors, adopts laser scattering method to monitor PM2.5, PM10, and can be integrated noise, temperature, humidity, light, wind speed and wind direction. The collected data is transferred to the intelligent cloud platform for processing,giving customers all the monitoring information.With data collection & transmission and video monitoring module can be added , its easy to realize real- time data collection and video display.

Features Specifications

LaserscatteringmeasurementofPM10,PM2.5,withquick-responseandwidemeasurementrange

Continuous24hoursonlinemonitoring
Ruggeddust-proof,rust-proofandmoisture-proofshell,IP65grade
SMSalerts
Quicksetupandeasyoperation

Enclosure	Water-proof,dust-proof,rust-proof,lightning protection, heat dissipation;GPRS transmission
Particle module	Detection Method:Light scattering laser photometer; Resolution:0. 1ug/m3； Measured Mass Fraction:PM2.5, PM10 Concentration Range:0～10000ug/m3 (0-2000ug/m3 ;0- 10mg/m3 ;0-30mg/m3 ) optional
Noise module	Range:30- 130dB；
Wind speed& wind direction module	Wind speed range:0~45m/s; accuracy：±0.3m/s;	Resolution:0. 1m/s； Start-up speed:≤0.5m/s；
	Wind Direction: Range :0-360° ; Resolution:1° Accuracy:±3°
Humidity & Temperature module	Temp:-40～120℃; resolution: 0. 1℃; Accuracy:±0.3℃;
	Humidity: Range0～100%RH;	Resolution:0. 1%RH；
	Accuracy:±2%RH
Barometric pressure	Range:10- 1100hPa Resolution:0. 1hPa; Accuracy:±0.3hPa
repeatability	≤±2%		Flow rate	1L/min ±5% constant rate
Precision	≤±10%		Interface	RS485/RS232
Resolution	0. 1μg/m3		Communication protocol	Modbus RTU
Max measurement	30000ug/m3		Protection grade	IP65
Detection Period	Default value 60s（1—999s adjustable,suggested≥6s）
Operating Temperature	Temperature:- 10℃~50℃;Humidity:﹤85%RH； Pressure:86～106kpa
Power supply	220V
Extensibility	O3, NO2, SO2,CO2 etc
